Long Ran Hybrid MPPT Solar Inverter 3.00KW 24V

Product specification

Model: Xanadu 3024 -Pro

Rated Power: 3000VA/3000W

Parallel Capability: NO

Operation Without Battery: Yes

Lithium Battery Communication: Yes (optional)

Dual Output: Yes (optional)

Input

Voltage: 220/230/240VAC

Selectable Voltage Range: 170~264Vac(for personal Computer) 90~280Vac (for home appliances)

Frequency Range: 50Hz/60Hz(Auto Sensing)

Output

AC Voltage Regulation(Batt.Mode): (220VAC~240VAC)±5%

Surge Power: 6000VA

Wave Form: Pure Sine Wave

Inverter Efficency(Peak): 93.5%

Transfer Time: 10ms(typcial)

BATTERY

Normal Voltage: 24Vdc

Floating Charge Voltage (settable): 27.6Vdc

Overcharge Protection: 30Vdc

SOLAR CHARGER & AC CHARGE

Max PV Array Open Circuit Voltage: 500Vdc

PV Array Voltage Range: MPPT 120-430Vdc

Num of MPP Trackers: 1

Maximum PV Input Power: 4000W

Maximum PV Input Current: 12A

Maximum Solar Charge Current: 120A

Maximum AC Charge Current: 120A

Maximum Charge Current: 120A

COMMUNICATION

Interface: USB/R485/CAN/DRY CONTACT

Wifi Monitoring: Yes(optional)

MECHANICAL SPECIFICATIONS

Machine Dimensions(HW*D)(mm): 310*467*116

Package Dimensions(HW*D)(mm): 570*375*200

Net Weight(kg): 9.25
